4 tina03e1 (0206) BPG400 v1.om
Contents
Product Identification 2
Validity 2
Intended Use 2
Functional Principle 3
Trademarks 3
1 Safety 6
1.1 Symbols Used 6
1.2 Personnel Qualifications 6
1.3 General Safety Instructions 7
1.4 Liability and Warranty 7
2 Technical Data 8
3 Installation 13
3.1 Vacuum Connection 13
3.1.1 Removing and Installing the Electronics Unit 15
3.1.2 Installing the Optional Extension 16
3.1.3 Using the Optional Baffle 17
3.1.3.1 Installing the Baffle 17
3.1.3.2 Replacing the Baffle 19
3.2 Electrical Connection 20
3.2.1 Use With INFICON VGC103 or VGC40x Vacuum Gauge Controller 20
3.2.2 Use With Other Controllers 21
3.2.2.1 Making an Individual Sensor Cable 21
3.2.2.2 Making a DeviceNet Interface Cable (BPG400-SD) 24
3.2.2.3 Making a Profibus Interface Cable (BPG400-SP) 25
3.2.3 Using the Optional Power Supply (With RS232C Line) 26
4 Operation 28
4.1 Measuring Principle, Measuring Behavior 28
4.2 Operational Principle of the Gauge 29
4.3 Putting the Gauge Into Operation 29
4.4 Degas 30
4.5 Display (BPG400) 30
4.6 RS232C Interface 32
4.6.1 Description of the Functions 32
4.6.1.1 Output String (Transmit) 32
4.6.1.2 Input String (Receive) 34
4.7 DeviceNet Interface (BPG400-SD) 35
4.7.1 Description of the Functions 35
4.7.2 Operating Parameters 35
4.7.2.1 Operating Software 35
4.7.2.2 Node Address Setting 35
4.7.2.3 Data Rate Setting 36
4.7.3 Status Lights 36
4.8 Profibus Interface (BPG400-SP) 37
4.8.1 Description of the Functions 37
4.8.2 Operating Parameters 37
4.8.2.1 Operating Software 37
4.8.2.2 Node Address Setting 37
4.9 Switching Functions (BPG400-SD, BPG400-SP) 38
4.9.1 Setting the Switching Functions 38
5 Deinstallation 40
