LED BOARD
Ref No. Part No. Description Qty.
J1 JC0118 CNCTR, 3PIN LED HARNESS 4” 1
LED1 DL0021 LED, 3MM GREEN 1
LED2 DL0021 LED, 3MM GREEN 1
MISC. SECTION
Ref No. Part No. Description Qty.
FETS-1 810065 MET, HTSNK .98X5.7 PWR SUPPLY 1
FETS-2 810066 MET, HTSNK CLIP HPS SERIES 4
FETS-3 MS0005 SILPAD, .009” .3C/W TO3P 3
FETS-4 MS0014 MISC, CERAMIC PLATE T0-220 1
MM25 HS0004 SCREW, #6-32X1/4 PAN PHIL ZNP 2
AC JC0114B CNCTR, 3PIN MALE/3PIN 1
FEM LOCK
CAB-TIE HS0072 SCREW, #4 HI-LOW PAN PHIL ZNP 4
CAB-TIE MC0003 CABLE, TIE 40MM W/METAL RING 4
CD+/- JC0112 CNCTR, CLASSD POWER CABLE 1
CLASSD JC0111 CNCTR, 8PIN RIBBON CABLE 3” 1
DC+/- JC0113 CNCTR, DC POWER CABLE 5” 1
F/L JC0116 CNCTR, SPEAKER CABLE 22” 1
F/L JC0117B CNCTR, 3PIN FEM/3PIN FEM 21” 1
HOUSE 930037 MISC, HPS AMP HOUSING PLASTIC 1
JC0116 TS0017 FIBREGLASS, HT210 #2AWG 3” 1
KNOB-1 RP0076 POT, KNOB GAIN/FREQUENCY 1
KNOB-2 RP0077 SWITCH KNOB PHASE 1
KNOB-3 RP0078 BUTTON KNOB MAIN POWER 1
LED DL0023 LED, REFLECTOR 1
SCREWS HS0072 SCREW, #4 HI-LOW PAN PHIL ZNP 2
SCREWS HS0073 SCREW, #6 HI-LOW PAN PHIL ZNP 8
FET-1 810064 MET, HTSNK .98X6.8 HPS250 FEA 2
FET-2 810066 MET, CLIP HPS SERIES 4
MM25 HS0004 SCREW, #6-32X1/4 PAN PHIL 4
POWER SUPPLY
PARTS FOUND ONLY ON THE 230V MODEL
Ref No. Part No. Description Qty.
Capacitors
C79 CE0098 22uf 50V 1
C6 CC0038 4700pf 1
C7 CE0129 150UF 400V 1
C11 CC0016 220pf 1
C14 CC0018 330pf 1
C19 CC0065 2200pf 1
C54 CE0132 4.7UF 1
Diodes
D4 DR0004 RECT. MUR140 ULTRA FAST 1
Z2, 4 DZ0022 ZENER 1N5271B 100V 2
Z3 DZ0014 ZENER 1N5244B 14V 1
Z6 DZ0004 ZENER 1N5242B 12V 1
Transistors
Q3 QB0047 TIP50 1
Q5 QB0027 PNP MPSA92 1
Q7 QB0027 MPSA92 1
Q8 QB0015 MPSA42 1
Q25 QB0048 PNP MPS6717 1
Resistors
R4 RM0190 MF 35.7Ω 1/4W 1
R16 RM0089 MF 2.43Ω 1/4W 1
R21 RM0336 MF 10Ω 1/4W 1% FLAMEPROOF 1
R31 RM0283 MF 442Ω 1/4W 5% 1
R33 RC0083 CF 100Ω 1/4W 1
R34 RM0130 CF 68Ω 1/4W 1
R38 RM0127 CF 49.9K 1/4W 1
R40 RX0025 WW 1Ω 1W 5% 1
R54 RM0336 MF 47Ω 1/4W 1% 1
R77 RC0104 CF 470Ω 1/4W 1
R92 RC0231 CF 300Ω 1/2W 1
10
Powered Subwoofer HPS-250
