Infinity HPS250 - Input, Filter, and Miscellaneous Parts; High Level Input Board Components List; Line Filter Board Components List

Ref No. Part No. Description Qty.
CD- MT0023 TERM, FASTON MALE 1
PCMT 187X032
CD+ MT0003 TERM, KWIKDISC .25 PCB MT 1
J3 JH0074 CNCTR, HEADER 8PIN LOCKING.1 1
J100 JH0063 CNCTR, HEADER 3PIN 1
R13 RP0056 POT, 5K 8MM HOR, BIAS 1
R28 RP0056 POT, 5K 8MM HOR, BIAS 1
R103 RP0063 POT, A10K SINGLE/BRACKET, GAIN 1
R116 RP0065 POT, B50K DUAL/BRACKET B021 1
FREQUENCY
SHIELD JH0028 CNCTR, HEADER 3PIN .100CTR 1
SPK- MT0031 TERM, FASTON .205 MALE PC MT 1
SPK+ MT0003 TERM, KWIKDISC .25 PCB MT 1
SW3 SR0017 SWITCH, 2 POLE 2PDT, PHASE 1
TH1 KS0019 THERMISTOR, 1
PTH9L04BB22TS2F330
HIGH LEVEL INPUT BOARD
Ref No. Part No. Description Qty
Capacitors
C1, 2 CE0106 CAP, E 22UF 35V BIPOLAR 6X11 2
C3, 4 CF0020 CAP, FY 4700PF 250V 20% 2
Resistors
R1 RW0037 RES, WW 470Ω 5W 5% 1
R2, 5 RC0059 RES, CF 47Ω 1/2W 5% 2
R3, 6 RM0085 RES, MF 2K 1/4W 1% 2
R4 RW0037 RES, WW 470Ω 5W 5% 1
Miscellaneous
BP1, 2, 3, 4 JC0086 CNCTR SINGLE BINDING POST RED 4
BP5, 6, 7,8 JC0087 CNCTR, SINGLE BINDING POST BLK 4
BP HN0015 NUT, HEX KEP #8-32 ZNP 8
F1 FS0021 FUSE, 2A 250V MDL Slo-Blo Fuse (120V) 1
FS0016 FUSE, 1A 250V MDL Slo-Blo Fuse (230V) 1
FUSE-2 FH0010 FUSE, HOLDER PANEL MT RANGLE 1
IEC-1 JC0076 CNCTR, AC IEC SOCKET .250TAB 1
IEC-2 HS0055 SCREW, #4-40X1/2 PAN PHIL BLK 2
IEC-3 HN0001 NUT, KEP 3/16AF 4-40 ZNP 2
RCA HS0041 SCREW, #4 SELF TAP PAN PHIL BL 1
MM25 HS0065 SCREW, #6-32X1/4 PAN PHIL BLK 1
SHIELD-2 HS0074 SCREW, #4-40X3/4 PHIL HEAD ZNP 1
SHIELD-3 HN0001 NUT, KEP 3/16AF 4-40 ZNP 1
STNOF-1 MZ0028 STANDOFF, ¼” AL ID.151 #409 1
STNOF-2 MZ0023 STANDOFF, .5” LOCKING 1
WIRE-2 WI0032 WIRE, POWER CORD SPT2/IEC 8FT 1
Ref No. Part No. Description Qty.
AC JC0114A CNCTR, 3PIN FEM/2XFEM FASTON 1
INPUT JC0117A CNCTR, 3PIN FEM/3PIN MALE 11” 1
OUTCUP 930035 CUP, OUTER PLASTIC HPS250 1
INCUP 930036 CUP, INNER PLASTIC HPS250 1
SCREW HS0072 SCREW, #4 HI-LOW PAN PHIL ZNP 2
CAB-TIE MC0003 CABLE, TIE 40MM W/METAL RING 2
T1 500086 120v XFMR, POWER AUDIO YT-6821 2
500092 230v XFMR POWER AUDIO YT-6893 2
LOW LEVEL INPUT BOARD
Ref No. Part No. Description Qty
Capacitors
C10 CE0106 CAP, E 22UF 35V BIPOLAR 6X11 1
C12 CF0020 CAP, FY 4700PF 250V 20% 1
Resistors
R10, 11 RM0029 RES, MF 3.01K 1/4W 1% 2
Miscellaneous
RCA1 JC0049 CNCTR, DUAL JACK RCA 1
J34, 36 JH0063 CNCTR, HEADER 3PIN 2
T10 500086 120V XFMR, POWER AUDIO YT-6821 1
230V XFMR, POWER AUDIO YT-6893 1
W5 MM0025 MISC, PC MT SCREW TERM 6-32 1
LINE FILTER BOARD
Ref No. Part No. Description Qty.
Capacitors
C5 CF0057 CAP, FX .22UF 250V 10% 1
C9 CE0004 CAP, E 2.2UF 450V 20% 1
Diode
D1 DB0009 RECT, 6A 400V BRIDGE TU604 1
Resistor
R1 RC0004 RES, CF 1.0MEGΩ 1/4W 5% 1
Miscellaneous
CORE-3 .BC0018 CORE, TOROID ZF42206TC 1
J1 JH0044 CNCTR, HEADER 3PIN .156CTR 1
L1 540126 230V ONLY XFMR, CURRENT CHOKE SQ 1
L2 540124 230V ONLY XFMR, CURRENT CHOKE SQ 1
L3 520024 XFMR, CURRENT CHOKE SQ 1
SW3 SR0009 SWITCH, PUSH TV5 1
Z1 KV0001 VARISTOR, 275V 100J .6W 1
9
Powered Subwoofer HPS-250
