POWER SUPPLY BOARD.
Ref No. Part No. Description Qty.
Capacitors
C2, 9, 11 CC0021 CAP, C 470 PF 600V 10% 3
C3, 73 CC0020 CAP, CA 470 PF 100V 5% 2
C4, 16 CE0010 CAP, E 22UF 50V 5X11 2.5 2
C6 CC0065 CAP, CA 2200PF 50V 5% 1
C7 CE0121 CAP, E 470UF 200V 20% 30X25 1
C12 CF0138 CAP, 2.2UF 250V 10% 27MMLS 1
C13, 65 CC0059 CAP, CA .1UF 100V 20% 2
C14 CC0032 CAP, C 2200PF 600V 10% 1
C17, 24, 29 CC0079 CAP, C .1UF 50V 20% .1LS 3
C19 CC0064 CAP, CA .022UF 50V 10% 1
C20 CC0065 CAP, CA 2200PF 50V 5% 1
C21 CF0008 CAP, F 2200PF 100DC 63AC 2% 5 1
C22, 23 CC0095 CAP, C 470PF 100V 5% 2
C26 CC0065 CAP, CA 2200PF 50V 5% 1
C28 CC0089 CAP, CA .01UF 100V 10% 1
C35 CC0059 CAP, CA .1UF 100V 20% 1
C36 CC0040 CAP, CA 4700PF 100V 10% 1
C55, 56, 80 CC0082 CAP, CA .1UF 50V 20% 4
81
C74 CC0072 CAP, CA 100PF 100V 10% 1
Diodes
D2, 5, 6, 7 DS0001 RECT, 100mA 75V SIGNAL 1N4148 6
12, 25
D9 DR0083 RECT, 4A 600V ULTRA FA MUR460 1
D23 DZ0018 2.5-37V PROGRAM. REF. TL431CLP 1
Z1, 5 DZ0002 500mW 12V 5% 1N5242B 2
Z6 DZ0004 ZENER, 500mW 18V 5% 1N5248B 1
Transistors
Q1, 8, 23 QB0017 TRANS, NPN 150V 0.6A 2N5551 3
Q3 QB0033 TRANS, NPN 250V 1A TO220 TIP47 1
Q4, 13, 14 QB0002 TRANS, NPN 40V .6A 2N4401 TO92 3
Q7, 22, 26 QB0018 TRANS, PNP 150V 0.6A 2N5401 3
Q9 QM0015 MOSFET, .18R 200V IRF640 1
Q19 QB0019 TRANS, NPN 40V 1A TO220 TIP29B 1
Q21 QB0013 TRANS, PNP 60V 1A TO220 TIP30B 1
Resistors
R2 RM0180 RES, MF 4.99K 1/4W 1% 1
R3 RC0037 RES, CF 2.0K 1/4W 5% 1
R4 RM0027 RES, MF 33.2K 1/4W 1% 1
R5, 6, 10 RM0011 RES, MF 100K 1/4W 1% 6
11, 28, 70
R7 RM0120 RES, MF 30.1K 1/4W 1% 1
R8 RC0127 RES, CF 30K 1/4W 5% 1
Ref No. Part No. Description Qty.
R9, 13, RM0079 RES, MF 750Ω 1/4W 1% 2
R12 RC0116 RES, CF 330K 1/4W 5% 1
R14, 15, 35, RM0114 RES, MF 20.0K 1/4W 1% 5
46, 88
R16 RM0034 RES, MF 4.32K 1/4W 1% 1
R17 RC0006 RES, CF 10K 1/4W 5% 1
R18 RM0022 RES, MF 47.0Ω 1/4W 2% 1
R19 RX0019 RES, MO 100Ω 2W 5% 1
R21 RM0336 RES, MF 47Ω 1/4W 1% 1
FLAME PROOF
R22, 26 RM0147 RES, MF 16.2K 1/4W 1% 2
R24, 51 BC0038 CORE, TOROID 77930A7 2
R25 RC0083 RES, CF 100K 1/4W 5% 1
R27, 37 RM0180 RES, MF 4.99K 1/4W 1% 2
R30, 50, 68, RM0001 RES, MF 1K 1/4W 1% 4
Z4
R31 RM0320 RES, MF 1.24K 1/4W 1% 1
R32 RM0260 RES, MF 1.0MΩ 1/4W 1% 1
R38 RC0127 RES, CF 30K 1/4W 5% 1
R39 RM0336 RES, MF 47Ω 1/4W 1% 1
R40 RW0022 RES. WW O.1Ω 2W 5% 1
R41 RC0260 RES, CF 2.4K 1/4W 5% 1
R43 RC0049 RES, CF 3.3K 1/4W 5% 1
R45 RM0035 RES, MF 4.75K 1/4W 1% 1
R47, 72 RM0120 RES, MF 30.1K 1/4W 1% 2
R49 RM0065 RES, MF 200Ω 1/4W 1% 1
R54 RM0012 RES, MF 100Ω 1/4W 1% 1
R71 RM0002 RES, MF 10.0K 1/4W 1% 1
R74 RM0043 RES, MF 6.81K 1/4W 1% 1
R77 RC0082 RES, CF 100K 1/2W 5% 1
R89, 90 RM0336 RES, MF 47Ω 1/4W 1% 2
FLAME PROOF
Integrated Circuits
U3 UA0003 OPAMP, QUAD 14PIN DIL LM324N 1
U5 UP0004 8 PIN UC3842N PWM CONTROLLER 1
Miscellaneous
B1 MM0025 MISC, PC MT SCREW TERM 6-32 1
B2 MM0025 MISC, PC MT SCREW TERM 6-32 1
CD- MT0023 TERM, FASTON MALE 1
PCMT 187X032
CD+ MT0003 TERM, .25 PCB MT 1
DC- MT0031 TERM, FASTON .205 MALE PC MT 1
DC+ MT0003 TERM, KWIKDISC .25 PCB MT 1
J3 JH0074 CNCTR, HEADER 8 PIN LOCKING.1 1
L3 BF0008 BEAD, FERRITE 1
L4 540115 IND, PIONEER TZ-SW05 1
L5 BF0007 BEAD, FERRITE 1
7
Powered Subwoofer HPS-250
HPS-250 ELECTRICAL PART LISTS
