Infinity HPS250 - Power Supply and Linear Board Parts; Power Supply Components List; Linear Board Components List

LINEAR BOARD.
Ref No. Part No. Description Qty.
Capacitors
C2, 4 CC0087 CAP, CA .01UF 100V 20% 2
C5, 7, 10 CF0045 CAP, F .1UF 63DC 5% 5MMLS 4
11
C6, 50, 64 CE0098 CAP, E 22UF 50V 5MMLS 85DEG 5
67, 101
C8, 9, 12 CE0106 CAP, E 22UF 35V BIPOLAR 6X11 4
101
C29 CC0082 CAP, CA .1UF 50V 20% 1
C52, 54, 57 CC0059 CAP, CA .1UF 100V 20% 4
58
C61, 62, CC0082 CAP, CA .1UF 50V 20% 5
110, 120,
121
C100 CF0099 CAP, F .68UF 63V 5% 1
C102 CC0065 CAP, CA 2200PF 50V 5% 1
C103, 104 CF0045 CAP, F .1UF 63DC 5% 5MMLS 4
105, 106
C107, 108 CF0119 CAP, F .047UF 100V 5% .2LS 2
C109 CC0098 CAP, CA .047U 50V 10% 1
C111 CE0018 CAP, E 100UF 25V 20% 5MMLS 1
C112 CE0003 CAP, E 2.2UF 50V 20% 105C 1
Diodes
D1-D18, DS0001 RECT, 100mA 75V SIGNAL 1N4148 28
100-109
Z1, 2 DZ0021 500MW 15V 5% 1N5245B 2
Resistors
R2 RM0001 RES, MF 1.0K 1/4W 1% 1
R3, 6, 18, RM0043 RES, MF 6.81K 1/4W 1% 4
21
R4, 5, 19, RM0031 RES, MF 3.32K 1/4W 1% 4
20
R7 RM0093 RES, MF 4.53K 1/4W 1% 1
R8, 9, 23, RM0071 RES, MF 332Ω 1/4W 1% 4
24
R10, 11, 25 RM0024 RES, MF 2.21K 1/4W 1% 4
26
R12, 27 RM0120 RES, MF 30.1K 1/4W 1% 2
R14, 29 RM0129 RES, MF 53.6K 1/4W 1% 2
R15, 30 RM0029 RES, MF 3.01K 1/4W 1% 2
R16 RC0083 RES, CF 100K 1/4W 5% 1
R19, 20 RM0031 RES, MF 3.32K 1/4W 1% 2
R22 RM0039 RES, MF 5.11K 1/4W 1% 1
R31, 84 RM0103 RES, MF 10.5K 1/4W 1% 2
R32 RC0273 RES, ZERO Ω JUMPER 1/4W 1
R33, 85 RM0073 RES, MF 392Ω 1/4W 1% 2
R34 RM0001 RES, MF 1.0K 1/4W 1% 1
R35, 36 RM0113 RES, MF 20.0K 1/4W 1% 2
Ref No. Part No. Description Qty
R37 RM0304 RES, MF 7.87K 1/4W 1% 1
R38 RM0197 RES, CF 3.6K 1/2W 5% 1
R39, 60 RC0006 RES, CF 10K 1/4W 5% 2
R58, 61, 62, RM0093 RES, MF 4.53K 1/4W 1% 4
63
R100 RM0085 RES, MF 2K 1/4W 1% 1
R101 RM0255 RES, MF 7.15K 1/4W 1% 1
R102 RM0072 RES, MF 365Ω 1/4W 1% 1
R105 RM0105 RES, MF 12.1K 1/4W 1% 1
R106 RM0306 RES, MF 14.7K 1/4W 1% 1
R107 RM0121 RES, MF 31.6K 1/4W 1% 1
R108 RM0001 RES, MF 1K 1/4W 1% 1
R109 RM0307 RES, MF 1.15K 1/4W 1% 1
R110 RM0191 RES, MF 20.5K 1/4W 1% 1
R111 RM0267 RES, MF 46.4K 1/4W 1% 1
R112 RM0302 RES, MF 2.15K 1/4W 1% 1
R113 RM0303 RES, MF 3.09K 1/4W 1% 1
R114 RM0267 RES, MF 46.4K 1/4W 1% 1
R115, 117 RM0114 RES, MF 22.1K 1/4W 1% 2
R118 RM0002 RES, MF 10.0K 1/4W 1% 1
R119 RM0013 RES, MF 11.0K 1/4W 1% 1
R120 RM0075 RES, MF 475Ω 1/4W 1% 1
R121, 122 RC0006 RES, CF 10K 1/4W 5% 5
123, 124,
126
R125 RC0127 RES, CF 30K 1/4W 5% 1
R127, 131 RC0037 RES, CF 2.0K 1/4W 5% 2
R128 RC0083 RES, CF 100K 1/4W 5% 1
R129 RC0014 RES, CF 15K 1/4W 5% 1
R130 RC0004 RES, CF 1.0MEGΩ 1/4W 5% 1
R140 RC0001 RES, CF 1.0K 1/2W 5% 1
Integrated Circuits
U1, 100 UA0009 OPAMP, QUAD 14PIN DIL TL084 2
U4 UF0013 OPTOCOUPLER, 6PIN MOC3012 1
U101 UA0003 OPAMP, QUAD 14PIN DIL LM324N 1
Transistors
Q1, 2, 5, 6 QB0017 TRANS, NPN 150V 0.6A 2N5551 4
Q3, 7 QM0044 MOSFET, 0.8R 200V PCH IRF9630 2
Q4, 8 QM0042 MOSFET, 0.8R 200V NCH IRF620 2
Q9 QM0035 JFET, N-CH J111 TO92 1
Q100 QM0035-S JFET, J111 SELECTED 1
Q101 QB0002 TRANS, NPN 40V .6A 2N4401 TO92 1
Miscellaneous
B1, 2, 3, 4 MM0025 MISC, PC MT SCREW TERM 6-32 4
8
Powered Subwoofer HPS-250
