Multiple Infinitys (DMX control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 5-pin XLR cable to connect the Infinity and other devices.
04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's PowerCON True1 socket,
then plug the other end of the mains power cord into proper electric power supply sockets, starting
with the first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Infinitys DMX Set Up
