Sweden 2.4GHz Wireless communication module
Depending on the transmitting power or transmitter module
W-DMX TRx Transmitter module, 2dBi Antenna, transmitting power
20dBm (100mW)
60 m (approx. through three concrete walls)
Wireless DMX Connection
The wireless receiving module “Pico G4 Receiver, 2.4GHz”, provided by Swedish WIRELESS SOLUTION, only
has a 2.4 GHz wireless signal receiving function. In order to match the wireless signal, please use the 50175
W-DMX MicroBox F-1 G5 Transceiver by WIRELESS SOLUTION. To control the status of the wireless
communication, please look at the blue LED indicator on the bottom of the fixture.
Wi-Fi Problems:
01) No connection with a transmitter.
The W-DMX indicator on the display will be gray.
02) Searching for a connection.
The W-DMX indicator on the display will be blinking quickly.
When the wireless DMX communication is normal, the W-DMX indicator on the display is always
green.
The Infinity cannot receive a wireless DMX signal and a DMX cable signal
at the same time.
Connect the Infinity to the Wireless DMX Signal Transmitter
The Infinity cannot actively match a random wireless signal transmitter.
In order to create a wireless match, please check the manual of your wireless signal transmitter.
We advise you to use the W-DMX MicroBox F-1 G5 Transceiver (50175) by WIRELESS SOLUTION (Fig. 06).
Disconnect the Infinity from the Wireless DMX Signal Transmitter
01) Turn off/unlink the W-DMX. In order to do so, deactivate W-DMX (see page 26-28 for more
information).
02) Unlink the Infinity (see page 26-28 for more information).
03) The Infinity will now be disconnected.
