8
Ordercode: 41507
Infinity S601 Profile
Description of the device
Features
The Infinity S601 Profile is a moving-head with high output and great effects.
Output
Lux @ 5m 6,5°: 29712
Lux @ 5m 45°: 1124
Beam angle: 6,5° - 45°
Light source: 1 x 500W White LED
Color temperature: 7500K
Electrical
Input voltage: 100-240V AC, 50/60Hz
Power consumption: 750W
Control
Onboard: Battery-powered, fixture-orientated touch display
Control modes: Stand-Alone, Manual, DMX-512, W-DMX, ArtNet
Control protocol: DMX, W-DMX, RDM, sACN, ArtNet
DMX channels: Basic (37 channels), Advance (57 channels), User (up to 57 channels)
Wireless DMX: Wireless Solutions Sweden
Optical system
Dimmer: 16 bit, 0-100%
Strobe: 0-20Hz
Selectable PWM: 0,6/1,5/2/4/6/15 kHz
Focus: Motorized auto focus
Iris: Motorized, 0-100%
Zoom: 8 or 16 bit (motorized)
Prisms: 3-facet circular prism & 5-facet linear rotating prism
Frost filter: Yes
Animation: Continuously bi-rotating flame wheel & digital motion FX
Framing System
Shutters: 4 dual-axis movement blades
System rotation: +/- 45°
Resolution: 16 bit
Movement
Pan: 540°
Tilt: 270°
Pan/Tilt resolution: 16 bit
Special: Fixture-orientated auto pan invert
Gobos & Colors
Gobo wheel 1: 6 glass gobos
Gobo size Gobowheel 1: Glass gobo: 31,95 mm (gobo size); 24 mm (image diameter); 1,1 mm (gobo
thickness)
Gobo wheel 2: 5 glass gobos
Gobo size Gobowheel 2: Glass gobo: 31,95 mm (gobo size); 26 mm (image diameter); 1,1 mm (gobo
thickness)
Gobo functions: Gobo-flow effect, Gobo shake
Gobo rotation: Bi-directional
Gobo index: 8 or 16 bit
Color wheel: 6 dichroic filters + white
CMY: 0-100%
CTO: 0-100%
Color functions: Split colors, Rainbow-flow effect, CMY macros
