49
Ordercode: 41507
Infinity S601 Profile
Channel 16 – Gobo rotation (gobo wheel 2)
0-45
Gobo indexing
46-126
Clockwise gobo rotation, from fast to slow
127-130
Stop
131-211
Counterclockwise gobo rotation, from slow to fast
212-255
Gobo wheel bounce effect, from small to big amplitude
Channel 17 – Prism
0-4
Not functional
5-127
Prism effect 1
128-255
Prism effect 2
Channel 18 – Prism rotation (gobo wheel 2)
0-45
Prism indexing
46-126
Clockwise prism rotation, from fast to slow
127-130
Stop
131-211
Counterclockwise prism rotation, from slow to fast
212-255
Prism bounce effect, from small to big amplitude
Channel 19 – Zoom
0-255
Zoom adjustment, from big to small
Channel 20 – Iris
0-255
Iris adjustment, from big to small
Channel 21 – Iris macros CH6 and CH8 must be open
0-63
Not functional
64-127
Macro switch, from slow to fast
128-191
Slow zoom out/fast zoom in, from slow to fast
192-255
Slow zoom in/fast zoom out, from slow to fast
Channel 22 – Focus
0-255
Focus adjustment
Channel 23 – Auto focus
0
Not functional
1-11
0-5 meters, auto focus gobo 1
12-22
6 meters, auto focus gobo 1
23-33
7 meters, auto focus gobo 1
34-44
8 meters, auto focus gobo 1
45-55
9 meters, auto focus gobo 1
56-66
10 meters, auto focus gobo 1
67-77
12,5 meters, auto focus gobo 1
78-88
15 meters, auto focus gobo 1
89-99
17,5 meters, auto focus gobo 1
100-110
20-60 meters, auto focus gobo 1
111-127
Auto detect distance gobo1
128-138
0-5 meters, auto focus gobo 2
139-149
6 meters, auto focus gobo 2
150-160
7 meters, auto focus gobo 2
161-171
8 meters, auto focus gobo 2
172-182
9 meters, auto focus gobo 2
183-193
10 meters, auto focus gobo 2
194-204
12,5 meters, auto focus gobo 2
205-215
15 meters, auto focus gobo 2
216-226
17,5 meters, auto focus gobo 2
227-237
20-60 meters, auto focus gobo 2
238-255
Auto detect distance gobo 2
