InfiRay AT300 Series User Manual

Precise Body Temperature Measurement Thermal Camera
责任 进取 敏行 合作
400-998-3088 www.IRaytek.com
IRay sensing
®
All Insight
- 4 -
2. Product Performance
Table 1 Product performance parameter
Model
AT3003F
AT6005F
Performance
Detector type
VOx Uncooled Infrared FPA Detector
Resolution
384×288
640×512
Lens Model
Focal Distance
7.8mm
15mm
Lens control
Support auto focus
Focus Type
Athermal
Athermal
FOV(Horizon×Vertical)
47°×35.6°
34.2°×27.4°
IFOV
2.1mrad
0.93mrad
Temperature Measurement Function
Measuring Range
0℃~50℃
Measurement accuracy@ ambient
temperature 16 ℃ ~ 32 ℃ (with
blackbody)
±2℃ @Target temperature 0℃~20℃
±0.6℃ @Target temperature 20℃~33℃
±0.3℃ @Target temperature 33℃~42℃
±0.6℃ @Target temperature 42℃~50℃
Effective temperature
measurement distance (meet the
measurement accuracy)
1m~5m
1m~5m
Temperature measurement tool
Arbitrary fixed spots
Full screen highest / lowest temperature spot capturing
Center spot temperature measurement
Line / area analysis tools
Manual temperature width selection
Ethernet
Network Interface
RJ45
