InFocus IN114BBST User Manual

RS232 Commands
頁 2
Model Name Notes
RS232 Setting
IN112AA
IN114AA/V11
IN116AA/V13
IN118AA
IN119AA
(w/o RS232)
IN112BB
IN114BB
IN114BBST/V31
IN118BB
IN118BBST
IN116BB
IN116BBST
IN119BB
IN188DD
Baud Rate: 9600; Data Bits: 8; Pari ty: None; Stop Bits: 1; Flow Control: None; UART16550 FIFO: Disabl e
Projector Return (Pass): P; Projector Ret urn (Fail): F
XX= 00-99 (Pojector's ID), XX= 00 is for all projectors
Note :
1. There i s a <CR> after all ASCII commands
2. 0D is the HEX code for <CR> in ASCII code
~XX70 23 7E 30 30 37 30 20 32 33 0D
'ر ﺎ ﻓ
No Yes Yes Yes Yes Farsi
~XX70 24 7E 30 30 37 30 20 32 34 0D !"#$%
No Yes Yes Yes Yes Hindi
~XX70 25 7E 30 30 37 30 20 32 35 0D Tiếng Việt
No Yes Yes Yes Yes Vietnamese
~XX70 26 7E 30 30 37 30 20 32 36 0D Bahasa Indonesia
No Yes Yes Yes Yes Indonesian
~XX70 27 7E 30 30 37 30 20 32 37 0D Română
No Yes Yes Yes Yes Romanian
~XX70 29 7E 30 30 37 30 20 32 39 0D Pilipino
No Yes Yes Yes Yes Filipino
~XX70 30 7E 30 30 37 30 20 33 30 0D Melayu
No Yes Yes Yes Yes Malay
~XX70 31 7E 30 30 37 30 20 33 31 0D বাংলা
No Yes Yes Yes Yes Bengali
~XX71 1 7E 30 30 37 31 20 31 0D
Front No Yes Yes Yes Yes
~XX71 2 7E 30 30 37 31 20 32 0D
Rear No Yes Yes Yes Yes
~XX71 3 7E 30 30 37 31 20 33 0D
Front-Ceiling No Yes Yes Yes Yes
~XX71 4 7E 30 30 37 31 20 34 0D
Rear-Ceiling No Yes Yes Yes Yes
~XX72 1 7E 30 30 37 32 20 31 0D
Top Left No Yes Yes Yes Yes
~XX72 2 7E 30 30 37 32 20 32 0D
Top Right No Yes Yes Yes Yes
~XX72 3 7E 30 30 37 32 20 33 0D
Centre No Yes Yes Yes Yes
~XX72 4 7E 30 30 37 32 20 34 0D
Bottom Left No Yes Yes Yes Yes
~XX72 5 7E 30 30 37 32 20 35 0D
Bottom Right No Yes Yes Yes Yes
S038 ~XX73 n 7E 30 30 37 33 20 a 0D Signal Frequency
n = -5 (a=2D 35) ~ 5 (a=35)
By signal
No Yes Yes Yes Yes
S039 ~XX74 n 7E 30 30 37 34 20 a 0D Signal Phase
n = 0 (a=30) ~ 63 (a=36 33)
By signal
No Yes Yes Yes Yes
S040 ~XX75 n 7E 30 30 37 35 20 a 0D Signal H. Position
n = -5 (a=2D 35) ~ 5 (a=35)
By timing
No Yes Yes Yes Yes
S041 ~XX76 n 7E 30 30 37 36 20 a 0D Signal V. Position
n = -5 (a=2D 35) ~ 5 (a=35)
By timing
No Yes Yes Yes Yes
S042 ~XX77 n 7E 30 30 37 37 20 aabbcc 0D
Security Security Timer
Month/Day/Hour
n = mm/dd/hh
mm= 00 (aa=30 30) ~ 12
(aa=31 32)
dd = 00 (bb=30 30) ~ 30
(bb=33 30)
hh= 00 (cc=30 30) ~ 24
(cc=32 34)
No Yes Yes Yes Yes
~XX78 1 ~nnnn 7E 30 30 37 38 20 31 0D
On with password
~nnnn = ~0000 (a= 7E 30 30
30 30)
~9999 (a=7E 39 39 39 39)
No Yes Yes Yes Yes
~XX78 0 ~nnnn 7E 30 30 37 38 20 32 20 a 0D
Off (0/2 for backward
compatible) with password
~nnnn = ~0000 (a= 7E 30 30
30 30)
~9999 (a=7E 39 39 39 39)
No Yes Yes Yes Yes
S044 ~XX79 n 7E 30 30 37 39 20 a 0D Projector ID
n = 00 (a=30 30) ~ 99 (a=39
39)
No Yes Yes Yes Yes
~XX80 1 7E 30 30 38 30 20 31 0D
On No Yes Yes Yes Yes
~XX80 0 7E 30 30 38 30 20 30 0D
Off (0/2 for backward
compatible)
No Yes Yes Yes Yes
S046 ~XX81 n 7E 30 30 38 31 20 a 0D Volume (Audio) n = 0 (a=30) ~ 10 (a=31 30) No Yes Yes Yes Yes
~XX90 1 7E 30 30 39 31 20 31 0D
16:10 No No No Yes No
~XX90 0 7E 30 30 39 31 20 30 0D
16:9 No No No Yes No
~XX91 1 7E 30 30 39 31 20 31 0D
On No Yes Yes Yes Yes
~XX91 0 7E 30 30 39 31 20 30 0D
Off No Yes Yes Yes Yes
~XX101 1 7E 30 30 31 30 31 20 31 0D
On No Yes Yes Yes Yes
~XX101 0 7E 30 30 31 30 31 20 30 0D
Off (0/2 for backward
compatible)
No Yes Yes Yes Yes
~XX102 1 7E 30 30 31 30 32 20 31 0D
On No Yes Yes Yes Yes
~XX102 0 7E 30 30 31 30 32 20 30 0D
Off (0/2 for backward
compatible)
No Yes Yes Yes Yes
~XX103 1 7E 30 30 31 30 33 20 31 0D
On No Yes Yes Yes Yes
~XX103 0 7E 30 30 31 30 33 20 30 0D
Off (0/2 for backward
compatible)
No Yes Yes Yes Yes
~XX104 0 7E 30 30 31 30 34 20 30 0D
None No No No No No
~XX104 1 7E 30 30 31 30 34 20 31 0D
Blue No Yes Yes Yes Yes
~XX104 2
Black No Yes Yes Yes Yes
~XX104 3 7E 30 30 31 30 34 20 33 0D
Red No Yes Yes Yes Yes
~XX104 4 7E 30 30 31 30 34 20 34 0D
Green No Yes Yes Yes Yes
~XX104 5
White No Yes Yes Yes Yes
~XX104 7 7E 30 30 31 30 34 20 37 0D
Logo No Yes Yes Yes Yes
~XX105 1 7E 30 30 31 30 35 20 31 0D
On No Yes Yes Yes Yes
~XX105 0 7E 30 30 31 30 35 20 30 0D
Off (0/2 for backward
compatible)
No Yes Yes Yes Yes
~XX109 1 7E 30 30 31 30 39 20 31 0D
On No Yes Yes Yes Yes
~XX109 0 7E 30 30 31 30 39 20 30 0D
Off (0/2 for backward
compatible)
No Yes Yes Yes Yes
~XX110 1 7E 30 30 31 31 30 20 31 0D
Bright No Yes Yes Yes Yes
~XX110 2 7E 30 30 31 31 30 20 32 0D
Eco No Yes Yes Yes Yes
~XX110 4 7E 30 30 31 31 30 20 34 0D
Dynamic No Yes Yes Yes Yes
S057 ~XX111 1 7E 30 30 31 31 31 20 31 0D Lamp Reset Yes No Yes Yes Yes Yes
~XX113 1 7E 30 30 31 31 33 20 31 0D
On No Yes Yes Yes Yes
~XX113 0 7E 30 30 31 31 33 20 30 0D
Off (0/2 for backward
compatible)
No Yes Yes Yes Yes
S059 ~XX106 n 7E 30 30 31 30 36 20 a 0D
Auto Power Off (min) “
(5 minutes for each step).”
n = 0 (a=30) ~ 180 (a=31 38
30)
No Yes Yes Yes Yes
S060 ~XX107 n 7E 30 30 31 30 37 20 a 0D
Sleep Timer (min) “
(30 minutes for each
step).”
n = 0 (a=30) ~ 990 (a=39 39
30)
No Yes Yes Yes Yes
S061 ~XX112 1 7E 30 30 31 31 32 20 31 0D
Reset to Default Yes (P.S
When security is off)
Yes with no password
(Security is Off)
No Yes Yes Yes Yes
S062 ~XX112 1 ~nnnn 7E 30 30 31 31 32 20 31 0D
Reset to Default Yes (P.S
When security is On/ Off)
Yes with no password
(Security is Off)
No Yes Yes Yes Yes
~XX115 1 7E 30 30 31 31 35 20 31 0D
On No Yes Yes Yes Yes
~XX115 0 7E 30 30 31 31 35 20 30 0D
Off (0/2 for backward
compatible)
No Yes Yes Yes Yes
~XX140 10 7E 30 30 31 34 30 20 31 30 0D
Up No Yes Yes Yes Yes
~XX140 11 7E 30 30 31 34 30 20 31 31 0D
Left No Yes Yes Yes Yes
~XX140 12 7E 30 30 31 34 30 20 31 32 0D
Enter (for Projection MENU) No Yes Yes Yes Yes
~XX140 13 7E 30 30 31 34 30 20 31 33 0D
Right No Yes Yes Yes Yes
~XX140 14 7E 30 30 31 34 30 20 31 34 0D
Down No Yes Yes Yes Yes
~XX140 15 7E 30 30 31 34 30 20 31 35 0D
Keystone + No Yes Yes Yes Yes
~XX140 16 7E 30 30 31 34 30 20 31 36 0D
Keystone – No Yes Yes Yes Yes
~XX140 17 7E 30 30 31 34 30 20 31 37 0D
Volume – No Yes Yes Yes Yes
~XX140 18 7E 30 30 31 34 30 20 31 38 0D
Volume + No Yes Yes Yes Yes
~XX140 19 7E 30 30 31 34 30 20 31 39 0D
Brightness No Yes Yes Yes Yes
~XX140 20 7E 30 30 31 34 30 20 32 30 0D
Menu No Yes Yes Yes Yes
~XX140 21 7E 30 30 31 34 30 20 32 31 0D
Zoom No Yes Yes Yes Yes
~XX140 28 7E 30 30 31 34 30 20 32 38 0D
Contrast No Yes Yes Yes Yes
~XX140 47 7E 30 30 31 34 30 20 34 37 0D
Source No Yes Yes Yes Yes
~XX195 0 7E 30 30 31 39 35 20 30 0D
Off No Yes Yes Yes Yes
S054
S055
S056
S058
S064
S065
S066
S035
S036
S037
S043
S045
S048
S049
IR Function
Test Pattern
Language
Projection
Menu Location
Security
Mute
Quick Resume
S050
S051
S052
S053
Lamp Reminder
Brightness Mode
Signal Power On
Screen Type
(Only for WXGA/WUXGA)
Signal Automatic
Only for WXGA/WUXGA
High Altitude
Information Hide
Keypad Lock
Background Color
Direct Power On
