InFocus IN114ST User Manual

9
Adjusting the image
If necessary, adjust the height of the projector by rotating the elevator foot to extend
the foot.
If necessary, rotate the leveling foot located at the rear of the projector.
Avoid placing your hands near the hot exhaust vent
at the front of the projector.
Position the projector the desired distance from the
screen at a 90 degree angle to
the screen.
See page 6 for a table listing scree
n
sizes and distances.
Adjust the zoom or focus.
If the image is not square, first make sure tha
t
the projector is perpendicular to the
screen. If the image is larger or smaller on the top or bottom edge of the screen,
press the top Keystone button to reduce the upper part of the image, and press the
bottom Keystone button to reduce the lower part.
If the left or right side of the screen is larger or smaller the other, you can turn the
projector to the left or to the right a few degrees to square the image.
Adjust the Contrast or Brightness in the
Basic Menu.
See page 25 for help with
these menu adjustments.
adjust distance
adjust zoom and focus
adjust keystone
Aspect Ratio
Auto Image
Brightness
Contrast
Keystone
Presets
Sharpness
Volume
Ceiling Mount
Advanced Menu
◄ Auto ►
Execute
50
50
50
Presentation
50
50
Off
( Basic Menu )
MDL: IN112
FW: 0.13
adjust Basic Menu
adjust height
elevator
foot

InFocus IN114ST Specifications

General

White Brightness	2700 lumens
Native Resolution	1024 x 768
Contrast Ratio	3, 000:1
Aspect Ratio	4:3
Throw Ratio Range	0.6 to 3.7:1
3D	yes
Minimum Screen Size	50 inches
Maximum Screen Size	300 inches
Minimum Distance	2 feet
Maximum Distance	12 feet
Video Input	vga, s-video, composite video
Inputs	composite video, s-video, usb, vga
OS Compatibility	mac, windows

Weight and Dimensions

Depth	9.3 inches
Height	2.8 inches
Width	11.2 inches
Net Weight	4.8 pounds
