InFocus IN114ST User Manual

25
Basic Menu
To adjust the following settings, highlight the setting, use the right and left arrows
to adjust the values.
Aspect Ratio:
Aspe
ct ratio is the ratio of the image width to image height. TV
screens are usually 4:3. HDTV and most DVDs are 16:9.
Select Auto to have the projector choose
the ratio.
Choose Native to see the
unmodified input with no resizing by the projector. Select 16:9 to watch enhanced
widescreen DVDs.
Auto Image:
resets the projector to the source.
Brightness: changes the
intensity of the image.
Contrast: controls the degree of difference between the lightest and darkest parts of
the picture and changes the amount of black and white in the image.
Keystone: adjusts the image vertically and makes
a squarer image. You can also
adjust keystone from the keypad.
Presets: Presets are provided that optimize the
projector for displaying computer
presentations and video images under certain conditions. Note: Users can save their
settings as a User Preset.
Sharpness: Changes the clarity of
the edges of a video image. Select a sharpness
setting.
Volume: increases
or decreases the
audio volume.
Ceiling Mount: turns the image upside down for ceiling-mounted projection.
Basic Menu
Aspect Ratio
Auto Image
Brightness
Contrast
Keystone
Presets
Sharpness
Volume
Ceiling Mount
Advanced Menu
◄ Auto ►
Execute
50
50
50
Presentation
50
50
Off
( Basic Menu )
MDL: IN112
FW: 0.13
increasing keystone decreasing keystone

InFocus IN114ST Specifications

General

White Brightness	2700 lumens
Native Resolution	1024 x 768
Contrast Ratio	3, 000:1
Aspect Ratio	4:3
Throw Ratio Range	0.6 to 3.7:1
3D	yes
Minimum Screen Size	50 inches
Maximum Screen Size	300 inches
Minimum Distance	2 feet
Maximum Distance	12 feet
Video Input	vga, s-video, composite video
Inputs	composite video, s-video, usb, vga
OS Compatibility	mac, windows

Weight and Dimensions

Depth	9.3 inches
Height	2.8 inches
Width	11.2 inches
Net Weight	4.8 pounds
