InFocus IN1503 User Manual

21
Using the remote control
The remote uses two (2) AA batteries. They are easily installed by removing the
cover from the remote’s back, aligning the + and - ends of the batteries, sliding them
into place, and then replacing the cover.
Caution:
• When disposing of the batterie
s, be sure to do so in an
enviromentally proper
manner.
• If the remote control gets wet, wipe it dry immediately.
• A
void excessive heat and humidity.
• Ensure the batteries' polarity (+/-) is aligned correctly.
• Do not mix new and old batteries together, or mix different types of batteries
together.
• Replace the batteries as soon as they run out.
• Remove batteries from the remote control when storing or not in use for a pro-
longed period.
To operate, point the remote at the front of t
he projector (not at the computer). The
range of optimum operation is about 15 feet (4.5m).
Press the remote’s Power button to turn the projector on and off (see page 13 for
shutdown info).
Press the remote’s Me
n
u button to open the projector’s menu system. Use the arrow
buttons to navigate, and the Select button to select features and adjust values in the
menus. See page 26 for more info on the menus.
The remote also has:
• Volume buttons to adjust the sound.
• Custom button that can be assigned to a special function, like Blank Screen or
Freeze (see page 29).
• Source button to switch between sources.
• Blank button to blank the screen.
• Presets button to select
stored settings (see page 27).
• Mute button to silence the audio.
• Auto Image
button to resynch the projector to the source
• Resize button to switch among aspect ratios (see page 27).
• Help
button to get help with connecting sources and improving the picture.
Troubleshooting the remote
• Make sure the batteries are installed in the proper orientation and are not dead.
• Make sure you’re pointing the remote at the projector or the screen, not the
computer, and are within the remote range of 15 feet (4.5m). For best results,
point the remote at the projector.
navigation
buttons

InFocus IN1503 Specifications

General

Matrix size	0.65 \
Native aspect ratio	16:10
Projection distance	0.76/3.51 m
Projection technology	DLP
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	1800:1
Screen size compatibility	- \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30/30 °
RS-232 ports	0
Focus	Manual
Offset	105 %
Throw ratio	0.72 - 0.86:1
Focal length range	- mm
Lamp power	165 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
RMS rated power	1 W
Number of built-in speakers	1
Audio (L/R) in	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	29 dB
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	170 W
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Product color	Black

Weight and Dimensions

Depth	222 mm
Width	235 mm
Height	83.8 mm
Weight	2000 g
Package weight	4300 g
