InFocus IN1503 User Manual

37
1
Turn off the projector and unplug the power cord.
2 Wait 60 minutes to allow the projector to cool thoroughly.
3 Remove the lamp door by (a) removing the screw on the side of the lamp door,
(b) lifting the door off.
4 Loosen the captive screw that attaches the lamp housing to the projector.
Carefully remove the lamp housing. Dispose of the lamp in an environmentally
proper manner.
5 Install the new lamp housing and tighten the screw.
6 Re-attach the lamp connector to the projector.
7 Replace the lamp door by sliding it into place.
8 Plug in the power cord and press the Power button to turn the projector back on.
9 To reset the lamp hour timer, navigate to the Status and Service menu and
select Reset Lamp Hours. See page 31 for details.
turn off and unplug
projector
wait 60 minutes
(a)
(b)
loosen screw

InFocus IN1503 Specifications

General

Matrix size	0.65 \
Native aspect ratio	16:10
Projection distance	0.76/3.51 m
Projection technology	DLP
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	1800:1
Screen size compatibility	- \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-30/30 °
RS-232 ports	0
Focus	Manual
Offset	105 %
Throw ratio	0.72 - 0.86:1
Focal length range	- mm
Lamp power	165 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
RMS rated power	1 W
Number of built-in speakers	1
Audio (L/R) in	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	29 dB
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	170 W
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Product color	Black

Weight and Dimensions

Depth	222 mm
Width	235 mm
Height	83.8 mm
Weight	2000 g
Package weight	4300 g
