InFocus IN32 User Manual

5
Connecting a computer
Required computer connections
Connect the black end of the computer cable to the Computer 1 connector
on the projector. Connect the blue end to the video port on your computer. If
you are using a desktop computer, you first need to disconnect the monitor
cable from the computer’s video port.
Some Macintosh® computers do not have a standard VESA-out video port.
If the supplied computer cable will not connect to your computer, purchase
the appropriate adapter from your Apple® reseller.
Connect the black power cable to the connector on the back of the projector
and to your electrical outlet.
The Power light on the Status Indicator Panel (page 12) turns amber.
NOTE: Always use the power cable that shipped with the projector.
Optional computer connections
To advance slides in a PowerPoint™ presentation using the up and down
arrow buttons on the remote, plug the USB connector on the computer cable
into the USB mouse connector on your computer.
To have sound with your presentation, connect an audio cable (sold sepa-
rately) to your computer and to the Audio In connector on the projector.
connect computer cable
connect power cable
connect computer cable
connect audio cable

InFocus IN32 Specifications

General

Number of colors	16.78 million colors
Vertical scan range	48 - 85 Hz
Horizontal scan range	15.625 - 85 kHz
Projection technology	DLP
Contrast ratio (typical)	1000:1
Screen size compatibility	32\
Projector native resolution	XGA (1024x768)
Display diagonal	0.7 \
Lamp type	SHP
Lamp power	200 W
Light source type	Lamp
Service life of light source	2000 h
I/O ports	2 Computer (DVI-M1 & VESA); 2 Video (S-Video 4-pin mini DIN & Composite RCA; 1 Audio (stereo RCA); 1 Serial Interface (RJ45)
Aspect ratio	4:3
Power supply type	90~265V @ 50-60Hz
Dimensions (WxDxH)	265 x 220 x 75 mm
Noise level	35 dB
Power consumption (typical)	260 W

Weight and Dimensions

Weight	2350 g
