Appendix
LitePro 580 User’s Guide 63
Specifications
The LitePro must be operated or stored within the limits of these
specifications.
Projection Lamp
Type 150W 65V metal halide short-arc
Life Average 600 hours to 50% of initial brightness
Fuse
Type 6.3A. 250V.T. 5x20mm
Power Requirements
100-120 VAC 3.5A, 50/60 Hz
220-240 VAC 1.3A, 50/60 Hz
Remote Control
Battery Three (3) AAA alkaline cells
Range Approximately 35 feet (10 m.) when aimed at the
projector or reflected off a white wall or projection
screen within 30° of the projection axis
Optical
Aspect ratio 4 (H) X 3(V)
Brightness average 200 lumens
(measured by ANSI 9 point method)
Uniformity 1.3:1 maximum
(measured by 12 point method)
Projection range 3.9 to 40.4 feet
(1.2 to 12.3 m)
Zoom ratio 1:1.4
Image size 21 in. to 300 in. (.5 m to 7 m)
Temperature
Operating 5° to 40° C
Non-operating -20° to 60° C
