18
Setting up the Projector
F
IGURE 17
Connecting the projector to a video player using an S-video cable and the audio con-
nectors on the standard A/V cable
4 Plug the A/V cable’s white connector into the left “audio out”
port on your video player. Plug the cable’s red connector into
the right “audio out” port on the video player (Figure 16 and
Figure 17).
CAUTION: Your video player
may also have a “Video Out” port
for a coaxial cable connection. Do
not use this to connect to the
projector.
5 Plug the A/V cable’s other white and red connectors into the
left and right (audio in) ports on the projector.
The projector is compatible with the three major broadcast video
standards: NTSC, PAL and SECAM. It automatically adjusts to
optimize its performance for the incoming video. You can also set
the video standard manually from the projector’s Controls menu;
see “Video Standard” on page 39.
A/V cable S-video cable
