19
Connecting an External Speaker and a Subwoofer
• To connect one or two external speakers, plug the speaker
cables into the separate red and white L R (audio out) con-
nectors on the projector.
NOTE: The external speakers
must have their own power source.
•
To connect a subwoofer, plug the subwoofer’s cable into the
connector on the projector.
FIGURE 18
Connecting an external speaker and a subwoofer
Connecting a Microphone
CAUTION: Always keep the
source volume at its lowest level
when installing the microphone.
For information about setting the
microphone level, see page 35.
•
To connect a microphone, plug the microphone cable into the
connector on the back of the projector.
FIGURE 19
Connecting a microphone
speaker cable
subwoofer cable
