51
APPENDIX
Specifications
The LitePro 610 and 620 must be operated and stored within the
temperature and humidity ranges specified.
Temperature
Operating
10 C to 40° C
Non-operating
-20 to 60
° C
Humidity
Operating and non-oper. 10% to 95% relative humidity, non-condensing
Dimensions
8.3 x 13 x 15.6 inches (21.3 x 33.3 x 40 cm)
Weight
24 lbs. (10.8 kg) unpacked
Altitude
Operating 0 to 10,000 feet (3048 meters)
Non-operating 20,000 feet (6096 meters)
Left and Right Audio Outputs
Frequency Response 10 Hz - 20 KHz
Output Impedance 1.2 K ohm nominal
Output Voltage 2 Vrms maximum (open circuit)
Connector Type red and white RCA jacks
Subwoofer Outputs
Frequency Response 10 Hz - 10 KHz
Output Impedance 200 ohms nominal
Output Voltage 2 Vrms maximum (open circuit)
Connector Type black RCA jack
Optics
Focus Range 5 feet to infinity
