3-2. LED Indicators and LCD Panel
LED indicators:
There are 4 LEDs on the front panel to show the UPS working status:
Mode LED Bypass Line Battery Fault
UPS On
● ● ● ●
No Output mode
○ ○ ○ ○
Bypass mode
●
○ ○ ○
AC mode
○
●
○ ○
Battery mode
○ ○
●
○
CVCF mode
○
●
○ ○
Battery Test
● ● ●
○
ECO mode
● ●
○ ○
Fault
○ ○ ○
●
Note: ● means LED is lighting, and ○ means LED is faded.
LCD panel :
