6. Specifications
E4 LCD TT
10K (S)
E4 LCD TT
15K (S)
E4 LCD TT
20K (S)
E4 LCD TT
30K (S)
10 kVA / 8 kW 15 kVA / 12 kW 20 kVA / 16 kW 30 kVA / 24 kW
INPUT
Voltage 3 Phase + Neutral 380/400/415 V
Low voltage
range
Battery mode
transfer
230 V
(P/N)
176 VAC ± 3% at 100% load / 110 VAC ± 3% at 50% load
Low line
comeback
230 V
(P/N)
186 VAC at 100% load / 120 VAC at 50% load
High voltage
range
Battery mode
transfer
230 V
(P/N)
276 VAC ± 3% at 100% load / 300 VAC ± 3% at 50% load
High line
comeback
230 V
(P/N)
266 VAC ± 3% at 100% load / 290 VAC ± 3% at 50% load
Frequency range 46~54 Hz at 50Hz / 56~64 Hz at 60Hz
Phase 3-phase with neutral and ground
Power factor
≧ 0.99 at 100% load
OUTPUT
Voltage 3 Phase + neutral 380/400/415 V
AC voltage regulation ± 1%
Frequency range (synchronized range) 46 ~ 54 Hz at 50 Hz / 56 ~ 64 Hz at 60 Hz
Frequency range (battery mode) 50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
Current crest ratio 3:1 max
Harmonic distortion
≦ 2% THD (linear load) / ≦ 5% THD (nonlinear load)
Transfer time
AC mode to battery mode Zero
Inverter to Bypass Zero (when phase lock fails, <4ms interruption occurs from inverter to bypass)
Inverter to Eco mode <10 ms
Waveform Pure sine wave
Backup time From 5 to 45 minutes depending on connected load
EFFICIENCY
AC mode 89% 90%
Battery mode 86-88% 89%
BATTERIES
Standard
Model
Battery type 12 V / 9 AH
Number
20
(adjustable 18-20)
2 x 20
(adjustable 18-20)
3 x 20
(adjustable 18-20)
Recharging time 9 hours recover to 90% capacity
Charging current (max.) 1.0 A ± 10% 2.0 A ± 10% 2.0 A ± 10% 4.0 A ± 10%
Charging voltage (max.) 273 VDC ± 1%
