84
* Derate capacity to 60% of capacity in CVCF mode and to 90% when the output voltage is adjusted to 208VAC.
**If the UPS is installed or used in a place where the altitude is above 1,000m, the output power must be derated one percent per 100m.
***Product specifications are subject to change without further notice.
Long-run
model (S)
Battery type Depending on applications
Number 18 – 20
Charging current (max.) 4.0 A ± 10% 4.0 A ± 10% 4.0 A ± 10% 12.0 A ± 10%
Charging voltage (max.) 273 VDC ± 1%
DISPLAY
LCD screen
UPS status, load level, battery level, Input/Output voltage,
discharge time and fault conditions
ALARMS
Battery mode Sounding every 4 seconds
Overload Sounding every second
Battery not connected Sounding every second
PHYSICAL CHARACTERISTICS
Standard
Model
Dimensions HxWxD (mm) 826 x 250 x 815 826 x 300 x 1000
Net weight (kg) 109 164 233,5
Long-run
model (S)
Dimensions HxWxD (mm) 826 x 250 x 592 826 x 250 x 815
Net weight (kg) 38 40 64
ENVIRONMENT
Humidity / Temperature <95 % RH @ 0- 40°C (without condensation)
Noise level
<60dB at 1
Meter
<65dB at 1 Meter
MANAGEMENT / COMMUNICATION
RS232 & USB communication ports Supports Windows family, Novell, Linux, Mac and FreeBSD
Optional SNMP Power management from SNMP manager and web browser
Dry contacts Dry contacts communication card for remote alarm
Software InfoPower
NORMS
Standard EC
EMC EN62040-2/2006
Low voltage (safety) EN62040-1-1/2003,2006/95/EC
WARRANTY
Warranty 2 years
