Sequence Outputs
Index 0x3604
Name Output Pulse Configuration
Object Code RECORD
Number of Elements 2
Value Description
Sub Index 1
Description Output Pulse
Data Type Unsigned16
Object Class sq
Access rw
PDO Mapping No
Value Range 0 the bit number is configured as Output
1 the bit number is configured as Output Pulse
Default Value 0
Sub Index 2
Description Output Pulse Duration
Data Type Unsigned16
Object Class sq
Access rw
PDO Mapping No
Unit ms
Value Range 1…16000
Default Value 0
This parameter defines the duration of the output activation.
