Ingenico iCT250 Manual

April 2012 Ingenico Telium CPTU02 User Manual 2-4
CONFIDENTIAL – Chase Paymentech Solutions, LLC - CONFIDENTIAL
Connecting a PIN pad
The iPP320 and iPP220 PIN pads are available as a customer facing PIN entry and/or card reader
device. Both the iPP320 and iPP220 connect to the USB port on the bottom of the terminal.
WARNING: Unplug the power from the terminal before connecting a PIN pad.
1. Open the Cable Cover (see above)
2. Connect the USB PIN pad cable
3. Remove one of the caps from the Magic Box cable to insert to accommodate the additional PIN
pad cable.
4. Reattach the cable cover and reconnect the power to the device.
iCT220 Example iCT320 Example
Connect the PIN pad cable to
the USB Host port on the
bottom of the terminal.
*With the power disconnected,
use scissors to remove one of the
rubber ‘caps’ from the Magic Box
cable.

Ingenico iCT250 Specifications

General

Memory	16 MB RAM, 128 MB Flash
Card Readers	Magnetic stripe, Smart card, Contactless
Operating System	Telium 2
Connectivity	Ethernet
Security	PCI PTS 3.x certified
Printer	Integrated thermal printer
Supported Cards	Visa, Mastercard, American Express, Discover
Display	128x64 pixel LCD, Backlit
Power Supply	External power adapter
