Inogen TAV - Air Delivery Performance; Oxygen Cylinder Duration - Pulse Mode

23
Air Delivery Performance
Delivered Oxygen Concentration: 21%
Accuracy (relative to Oxygen Delivery Performance): Within 10%
Oxygen Cylinder Duration - Pulse Mode
The following tables provide approximate duration times for B (M-6) and E (M-24) oxygen tanks.
Please note that these gures are only meant to serve as a guide.
Note: Actual tank durations will depend on your actual breathing rate, the initial fullness of the
tank, and other factors such as leaks and gauge accuracy.
Table 1: Cylinder Size B (M-6) 150 liters when full
Breaths per Minute
12 14 16 18 20 22 24 26 28 30
Flow Setting Tank duration in hours
1 20.8 17.9 15.6 13.9 12.5 11.4 10.4 9.6 8.9 8.3
2 10.4 8.9 7.8 6.9 6.3 5.7 5.2 4.8 4.5 4.2
3 6.9 6.0 5.2 4.6 4.2 3.8 3.5 3.2 3.0 2.8
4 5.2 4.5 3.9 3.5 3.1 2.8 2.6 2.4 2.2 2.1
5 4.2 3.6 3.1 2.8 2.5 2.3 2.1 2.0 1.8 1.7
Table 2: Cylinder Size E (M-24) 616 liters when full
Breaths per Minute
12 14 16 18 20 22 24 26 28 30
Flow Setting Tank duration in hours
1 85.6 73.3 64.2 57.0 51.3 46.7 42.8 39.5 36.7 34.2
2 42.8 36.7 32.1 28.5 25.7 23.3 21.4 19.7 18.3 17.1
3 28.5 24.4 21.4 19.0 17.1 15.6 14.3 13.2 12.2 11.4
4 21.4 18.3 16.0 14.3 12.8 11.7 10.7 9.9 9.2 8.6
5 17.1 14.7 12.8 11.4 10.3 9.3 8.6 8.0 7.3 6.8
Example 1: M6 tank, breaths/minute = 16, ow setting = 3
• Using table 1, nd the breath rate of 16 at the top of the table
• Move down from 16 until you reach the row for ow setting = 3
• The approximate tank duration for this example = 5.2 hours
Example 2:E tank, breaths/minute = 18, ow setting = 2
• Using table 2, nd the breath rate of 18 at the top of the table
• Move down from 18 until you reach the row for ow setting = 2
• The approximate tank duration for this example = 28.5 hours
