Installation

WARNING

◆ Installation must be carried out by the specialists who have received the necessary electrical

training and understood enough electrical knowledge.

◆ Disconnect all external power supplies of the system before removing/installing the module.

Failure to do so may result in electric shock, module fault or malfunction.

◆ Do not use the PLC where there are dust, oil smoke, conductive dust, corrosive or combustible

gases, or exposed to high temperature, condensation, wind & rain, or subject to vibration and

impact. Electric shock, 󶍾re and malfunction may also result in damage or deterioration to the

product.

◆ The PLC is open-type equipment that must be installed in a control cabinet with lock (cabinet

housing protection ＞ IP20). Only the personnel who have received the necessary electrical

training and understood enough electrical knowledge can open the cabinet.

CAUTION

◆ Prevent metal 󶍾lings and wire ends from dropping into ventilation holes of the PLC during

installation. Failure to comply may result in 󶍾re, fault and malfunction.

◆ Ensure there are no foreign matters on ventilation surface. Failure to comply may result in poor

ventilation, which may cause 󶍾re, fault and malfunction.

◆ Ensure the module is connected to the respective connector securely and hook the module

󶍾rmly. Improper installation may result in malfunction, fault or fall-o󶍽.

Wiring

WARNING

◆ Wiring must be carried out by personnel who have received the necessary electrical training

and understood enough electrical knowledge.

◆ Disconnect all external power supplies of the system before wiring. Failure to comply may

result in electric shock, module fault or malfunction.

◆ Install the terminal cover attached to the product before power-on or operation after wiring is

completed. Failure to comply may result in electric shock.

◆ Perform good insulation on terminals so that insulation distance between cables will not

reduce after cables are connected to terminals. Failure to comply may result in electric shock or

damage to the equipment.

Inovance GR10-EC-6SW User Manual
