9
1.5 Output Specications
The output ports use dry contact output, which is closed in the ON state and
open in the OFF state.
Item
High-speed Output Port
(Y0–Y7)
General Output Port
(Y10–Y15)
Signal circuit supply voltage 5–24 V DC
Output type Transistor NPN output
Circuit insulation Optocoupler insulation
Open-circuit leakage current < 0.1 mA/30 V DC
Min. load
12 mA for high-speed
output above 10 kHz
5 mA
Max. output current
Resistive load
0.8A/4points,0.2A per
point
0.8 A/4 points; 1.6 A/6
points
Inductive load 7.2 W/24 V DC 12 W/24 V DC
ON response time
High-speed output (12
mA load): 1 μs
0.5 ms
OFF response time
High-speed output frequency Max. 200 kHz/channel –
Output common terminal
One common terminal for each group; isolation of
common terminals between groups
Fuse None
The high-speed output circuit provides short circuit protection, namely,
automatic output locking. Outputs can be unlocked in the OFF state.
The protection function can withstand 100 energy impacts per second.
Therefore, do not connect high-speed outputs to a capacitive load more than 10
μF to prevent the equipment damaged.
