Inovance H5U Series - Product Information; Model and Nameplate; External Ports

5
1 Product Information
1.1 Model and Nameplate
24V DC
D
H
INOVANCE PLC
5U
Product series
H5U-1614MTD-A16
16
16 inputs
Type
Transistor output
MT
14
14 outputs
Number of Axes
8 axes
A8
No.
16 axes
A16
No.
32 axes
blank
Product Information Number of I/O Points Power Supply
Figure 1 Model and nameplate
Model Category Description Code
H5U-1614MTD PLC
H5U series PLC with 16 inputs and 14 outputs
(32-axis)
01440087
H5U-1614MTD-A16 PLC
H5U series PLC with 16 inputs and 14 outputs
(16-axis)
01440235
H5U-1614MTD-A8 PLC
H5U series PLC with 16 inputs and 14 outputs
(8-axis)
01440236
H5U-1614MTD-A8S PLC
H5U series PLC with 16 inputs and 14 outputs
(8-axis), No CAN and Cam
01440315
1.2 External Ports
1
2
3
4
5
6 7 8
10
9
11
13
12
H5U-1614MT D
Figure 2 PLC ports
