11
Denition Terminal Terminal Denition
General input X13 X17 General input
General input X12 X16 General input
General input X11 X15 General input
General input X10 X14 General input
High-speed input X3 X7 Medium-speed input
High-speed input X2 X6 Medium-speed input
High-speed input X1 X5 Medium-speed Input
High-speed input X0 X4 Medium-speed input
High-speed input common
terminal
SS0 SS1 General and high-speed input
common terminal
General output Y12 Y15 General output
General output Y11 Y14 General output
General output Y10 Y13 General output
General output common terminal C1 C1 General output common terminal
High-speed output Y3 Y7 High-speed output
High-speed output Y2 Y6 High-speed output
High-speed output Y1 Y5 High-speed output
High-speed output Y0 Y4 High-speed output
High-speed output common
terminal
C0 C0 High-speed output common
terminal
◆
The naming conventions for screenprint and labels of controller
terminals dier. Their mapping may be dened, for example, label
CH0-X0 = screenprint X0, label CH1-Y10 = screenprint Y10, and label
COM0 = screenprint C0, with CH0 for channel 0 and CH1 for channel
1.
◆
Terminals of CH0 may distinguish between COM0 and SS0, and
those of CH1 between COM1 and SS1. For example, CH0-Y0
corresponds to COM0, and CH0-X0 corresponds to SS0.
◆
SS0 is the common terminal for X0–X3 (high-speed inputs) of
channel 0, and SS1 is the common terminal for X4–X17 (medium-
speed inputs and general inputs) of channel 1.
◆
C0 is the common terminal for the Y0–Y7 output terminals of
channel 0, and C1 is the common terminal for the Y10–Y15 output
terminals of channel 1.
■ Wiring Precautions
1) The maximum length of the expansion cable for a high-speed I/O port must
not exceed 3.0 m.
2) In the routing process, avoid bundling expansion cables with the power cable
(of high voltage and current) and other cables that transmit strong interfering
signals. Route expansion cables separately and avoid parallel routing.
