2 Mechanical Design Reference
■
Exterior and Dimensions
83.0
95.0
90.0
H5U-1614MT D
Figure 3 Exterior and dimensions (mm) of the PLC
3 Electrical Design Reference
3.1 Terminal Layout
H5U-1614MTD
Figure 4 Terminal layout of the PLC
