■ Safety Levels and Denitions
:
Indicates that failure to comply with the notice may result in severe personal
injury or even death.
:
Indicates that failure to comply with the notice may result in severe personal
injury or even death.
: Indicates that failure to comply with the notice may result in minor or moderate
personal injury or damage to the equipment.
Keep this user guide properly for reference when necessary and forward this guide to the end
user.
Control System Design
◆ External circuits must include an emergency stop circuit, a protective circuit, a forward/reverse
operation interlocked circuit, and an upper position limit and lower position limit interlocked
circuit (or reciprocating motion limit interlocked circuit) to prevent damage to the equipment.
◆ Provide a fault protection circuit outside the equipment to prevent unsafe accidental
mechanical movement (for example, unexpected movement in the input/output control area
that cannot be monitored by the equipment).
◆ A user program is required to protect the system when a display, control, communication, or
power failure occurs on the equipment.
◆ When designing the system, ensure that a communication fault between the equipment and
its main controller will not lead to equipment malfunction, which could result in personal
injury or equipment damage.
◆ During operation, keep live objects away from the metal housing of the equipment.
◆ Do not set any switch on the touch screen that may result in personal injury or equipment
damage. A separate switch is required for important operations to avoid accidents caused by
abnormal output or faults.
◆ Do not set any touch switch on the equipment to control safe operations, such as an
emergency stop. Use a dedicated physical switch instead. Failure to comply may result in
severe personal injury or equipment damage.
◆ Do not use the equipment as an alarm device for serious accidents such as serious personal
injury, equipment damage, or system shutdown. Use dedicated hardware and/or mechanical
interlocks for designing important alarms and related control and trigger devices.
