IS620P User Manual Chapter 7 Function Code Table
- 175 -
Function
Code
Parameter
Name
Setting Range Unit Default
Effective
Time
Property
Control
Mode
H05 40
Mechanical
home offset
and action
after reaching
limit switch
0: H05-36 as
coordinate for
home return, trigger
home return and
nd home reversely
after reaching limit
switch
1: H05-36 as
relative offset for
home return, trigger
home return and
nd home reversely
after reaching limit
switch
2: H05-36 as
coordinate for
home return,
automatically
nd zero position
reversely after
reaching limit switch
3: H05-36 as
relative offset
for home return,
automatically
nd zero position
reversely after
reaching limit switch
- 0 Immediate At stop P
H05 41
Output polarity
of Z pulse
0: Positive (Z pulse
being high level)
1: Negative (Z pulse
being low level)
- 1
Power-on
again
At stop P
Group H06: Speed Control Parameters
Function
Code
Parameter
Name
Setting Range Unit Default
Effective
Time
Property
Control
Mode
H06 00
Main speed
reference A
source
0: Digital setting (H06-
03)
1: AI1
2: AI2
- 0 Immediate At stop S
H06 01
Auxiliary speed
reference B
source
0: Digital setting (H06-
03)
1: AI1
2: AI2
3: 0 (No function)
4: 0 (No function)
5: Multi-speed
reference
- 1 Immediate At stop S
