Inovance MD210 Series User Manual

Page 27 of 43
F0-27
Binding command
source to frequency
source
0000 to 9999
N.A. 0000
9 Group F1: Motor Parameters
Function
Code
Parameter Name
Setting Range
Unit
Default
Commission
F1-00
Motor type selection
0: Common asynchronous motor
1: Variable frequency asynchronous motor
N.A.
0
F1-01
Rated motor power
0.1 to 7.5
kW
Model
dependent
F1-02
Rated motor voltage
1 to 1000
V
Model
dependent
F1-03
Rated motor current
0.01 to 655.35
A
Model
dependent
F1-04
Rated motor frequency
0.01 to Max. frequency
Hz
Model
dependent
F1-05
Rated motor speed
1 to 65535
RPM
Model
dependent
F1-06
Stator resistance
(asynchronous motor)
0.001 to 65.535
Ω
Model
dependent
F1-07
F1-08
F1-09
Reserved
N.A.
N.A. N.A. N.A.
F1-10
No-load current
(asynchronous motor)
0.01 to F1-03
A
Model
dependent
9 Group F3: V/F Control
Function
Code
Parameter Name
Setting Range
Unit
Default
Commission
F3-00
V/F curve setting
0 to 9
N.A.
0
F3-01
Torque boost
0.0 to 30.0
%
Model
dependent
F3-02
Cut-off frequency of
torque boost
0.00 to Max. output frequency
Hz
50.00
F3-03
Multi-point V/F
frequency 1 (F1)
0.00 to F3-05
Hz 0.00
F3-04
Multi-point V/F voltage
1 (V1)
0.0 to 100.0
%
0.0
F3-05
Multi-point V/F
frequency 2 (F2)
F3-03 to F3-07
Hz
0.00
F3-06
Multi-point V/F voltage
2 (V2)
0.0 to 100.0
% 0.0
F3-07
Multi-point V/F
frequency 3 (F3)
F3-05 to rated motor frequency (F1-04)
Hz
0.00
F3-08
Multi-point V/F voltage
3 (V3)
0.0 to 100.0
%
0.0
F3-09
V/F slip compensation
gain
0 to 200.0
% 0.0
F3-10
V/F over-excitation
gain
0 to 200
%
64
F3-11
V/F oscillation
suppression gain
0 to100
%
Model
dependent
