2.2 Terminals
9 Terminals of Main Circuit
Table 2-1: Main circuit terminals of the single-phase
Terminal
Terminal Name
Description
L1, L2
Single-phase power supply input terminals
Connect to the single-phase 220 VAC power supply.
P(+), (-)
Positive and negative terminals of DC bus
Common DC bus input point.
P(+), BR
Connecting terminals of braking resistor
Connect to a braking resistor.
U, V, W
AC drive output terminals
Connect to a three-phase motor.
Grounding terminal Must be grounded.
Table 2-2: Main circuit terminals of the three-phase
Terminal
Terminal Name
Description
R, S, T
Three-phase power supply input terminals
Connect to the three-phase 220/380 VAC power supply.
P(+), (-)
Positive and negative terminals of DC bus
Common DC bus input point.
P(+), BR
Connecting terminals of braking resistor
Connect to a braking resistor.
U, V, W
AC drive output terminals
Connect to a three-phase motor.
Grounding terminal
Must be grounded.
