Inovance MD210 Series User Manual

Page 9 of 43
3.2 Step By Step Setup
9 Setup Flowchart
Any problem, refer to Chapter 4 “TROUBLESHOOTING”
Set S-curve if needed
Get familiar with keypad
Set motor parameters
Set frequency reference
Set operation mode
Check nameplate and wiring
Apply main power to AC drive
Set start mode
Set stop mode
Set acceleration and deceleration time
Set DI and DO if needed
Set startup frequency if needed
Set DC injection braking if needed
Set pre-excitation if needed
RUN!
Check motor rotation and machine travelling direction
Check motor current
2
3
4
5
6
7
8
9
10
1
11
12
Refer to Chapter 1 and 2
Refer to User Manual
Refer to User Manual
