Inovance MD210 Series User Manual

Page 41 of 43
9 Group A6: AI Curve Setting
Function
Code
Parameter Name
Setting Range
Unit
Default
Commission
A6-00
AI curve 4 minimum
input
-10.00 to A6-02
V 0.00
A6-01
Corresponding setting
of AI curve 4 minimum
input
-100.0 to 100.0
% 0.0
A6-02
AI curve 4 inflexion 1
input
A6-00 to A6-04
V
3.00
A6-03
Corresponding setting
of AI curve 4 inflexion
1 input
-100.0 to 100.0
% 30.0
A6-04
AI curve 4 inflexion 1
input
A6-02 to A6-06
V
6.00
A6-05
Corresponding setting
of AI curve 4 inflexion
1 input
-100.0 to 100.0
% 60.0
A6-06
AI curve 4 Max. input
A6-06 to 10.00
V
10.00
A6-07
Corresponding setting
of AI curve 4 Max.
input
-100.0 to 100.0
% 100.0
A6-08
AI curve 5 minimum
input
-10.00 to A6-10
V 0.00
A6-09
Corresponding setting
of AI curve 5 minimum
input
-100.0 to 100.0
% 0.0
A6-10
AI curve 5 inflexion 1
input
A6-08 to A6-12
V
3.00
A6-11
Corresponding setting
of AI curve 5 inflexion
1 input
-100.0 to 100.0
% 30.0
A6-12
AI curve 5 inflexion 1
input
A6-10 to A6-14
V
6.00
A6-13
Corresponding setting
of AI curve 5
inflexion
1 input
-100.0 to 100.0
% 60.0
A6-14
AI curve 5 Max. input
A6-14 to 10.00
V
10.00
A6-15
Corresponding setting
of AI curve 5 Max.
input
-100.0 to 100.0
% 100.0
A6-24
Jump point of AI1 input
corresponding setting
-100.0 to 100.0
% 0.0
A6-25
Jump amplitude of AI1
input corresponding
setting
0.0 to 100.0
% 0.5
9 Group AC: AI/AO Correction
Function
Code
Parameter Name
Setting Range
Unit
Default
Commission
AC-00
AI1 measured voltage
1
0.500 to 4.000
V
Factory
corrected
AC-01
AI1 displayed voltage
1
0.500 to 4.000
V
Factory
corrected
AC-02
AI1 measured voltage
2
6.000 to 9.999
V
Factory
corrected
AC-03
AI1 displayed voltage
2
6.000 to 9.999
V
Factory
corrected
AC-12
AO1 target voltage 1
0.500 to 4.000
V
Factory
corrected
AC-13
AO1 measured voltage
1
0.500 to 4.000
V
Factory
corrected
AC-14
AO1 target voltage 2
6.000 to 9.999
V
Factory
corrected
AC-15
AO1 measured voltage
2
6.000 to 9.999
V
Factory
corrected
