5. Quick Setup
- 99 -
5
CONTINUE Para. Parameter name Default Commission
Set accel/decel time F0-17 Acceleration time 1 model
dependent
If smooth accel/decel
is requested
0 : Linear acceleration/deceleration
1: Static S-curve acceleration/deceleration
2: Dynamic S-curve acceleration/
deceleration
0.00 to 650.00s (if F0-19 = 2)
0.0 to 6500.0s (if F0-19 = 1)
0 to 65000s (if F0-19 = 0)
F0-18 Deceleration time 1 model
dependent
0.00 to 650.00s (if F0-19=2)
0.0 to 6500.0s (if F0-19=1)
0 to 65000s (if F0-19=0)
Set S-curve F6-07 Acceleration/Deceleration mode 0
0 : Linear acceleration/deceleration
1: Static S-curve acceleration/deceleration
2: Dynamic S-curve acceleration/deceleration
F6-08 Time proportion of S-curve at Accel start 30.0
0.0% to (100.0% - F6-09)
F6-09 Time proportion of S-curve at Accel end 30.0
0.0% to (100.0% - F6-08)
CONTINUE Para. Parameter name Default Commission
To Next Page
