Inovance MD290T45G/55P User Manual

5. Quick Setup
- 98 -
5
CONTINUE Para. Parameter name Default Commission
if an analog output is
used
F5-01
FM (switch signal) function selection 0
34: Zero current status
35: IGBT temperature reached
36:Software current limit exceeded
37: Frequency lower limit reached (having output at stop)
38: Alarm output
39: Motor overheat warning
40: Current running time reached
41: Fault output (no output at undervoltage)
F5-02 Relay function selection(T/A-T/B-T/C) 2
Setting range same as FM;
F5-03 Relay function selection (P/A-P/B-P/C) 0
Setting range same as FM; the relay P/A-P/B-P/C is
on extension I/O card.
F5-04 DO1 function selection 1
Setting range same as FM
F5-05 Extension card DO2 function selection 4
Setting range same as FM
F5-06 FM (pulse signal) function selection 0
0: Running frequency
1: Set frequency
2: Output current
3: Reserved
4: Output power
5: Output voltage
6: Pulse input
7: AI1
8: AI2
9: AI3
10: Length
11: Count value
12: Communication setting
13: Motor rotational speed
14: Output current
15: Output voltage
16: Reserved
Set AO function F5-07 AO1 function selection 0
Setting range same as F5-06
F5-08 AO2 function selection 1
Setting range same as F5-06; AO2 is on extension card.
