8. Peripherals and Options
- 236 -
8
Ƶ
Mounting Dimensions of MDBUN Series Braking Unit
ĭ5
60
236
247
165
224
110
Unit: mm
Always mount MDBUN series braking unit in an upright position.
Hot air
Cold air
100
50 50
100
Upright
For use and installation of MDBUN series braking unit, refer to the MDBUN Series Braking Unit
User Manual.
