Inovance MD290T45G/55P User Manual

Appendix
- 301 -
12
Reactor Series A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) G
182A 210 max.180 max.185 175 97 8 x 12
I
10
230A 240 220 190 119 11 x 15
I
12
280A 240 235 190 133 11 x 15
I
12
330A 240 240 190 135 11 x 15
I
12
400 and 500A 240 220 190 119 11 x 15
I
11
600 and 680A 240 230 190 128 11 x 15
I
11
790A 300 218 240 136 11 x 15
I
11
910A 300 228 240 148 11 x 15
I
11
1100A 360 250 310 144 11 x 15
I
11
Ƶ
Common-mode Filter
7KHFRPPRQPRGH¿OWHULVLQVWDOOHGRQRXWSXWVLGHFORVHWR$&GULYHWRUHGXFHEHDULQJ
current and reduce interference on surrounding devices.
7KHIROORZLQJ¿JXUHVKRZVLQVWDOODWLRQRIFRPPRQPRGH¿OWHU
PEWVU
Cable length
< 300 mm
Magnetic ring
(wind three turns)
7KHIROORZLQJ¿JXUHVKRZVSK\VLFDODSSHDUDQFHRIIHUULWHFRUH
Common-mode Filter Model SN Dimensions (Outer Diameter x Inner
Diameter x Thickness) (mm)
DY644020H 11013031 64 x 40 x 20
DY805020H 11013032 80 x 50 x 20
DY1207030H 11013033 120 x 70 x 30
