Appendix
- 310 -
12
Para. No. Para. Name Setting Range Default Property Page
F1-06 Stator resistance WRȍ$&GULYHSRZHU
N:
WRȍ$&GULYH
power > 55 kW)
Auto-
tuning
dependent
ƾ
1
4
5
F1-07 Rotor resistance WRȍ$&GULYHSRZHU
N:
WRȍ$&GULYH
power > 55 kW)
Auto-
tuning
dependent
ƾ
1
4
5
F1-08 Leakage inductive reactance 0.01 to 655.35 mH (AC drive
SRZHUN:
0.001 to 65.535 mH (AC drive
power > 55 kW)
Auto-
tuning
dependent
ƾ
1
4
5
F1-09 Mutual inductive reactance 0.1 to 6553.5 mH (AC drive power
N:
0.01 to 655.35 mH (AC drive
power > 55 kW)
Auto-
tuning
dependent
ƾ
1
4
5
F1-10 No-load current $WR)$&GULYHSRZHU
55 kW)
0.1 A to F1-03 (AC drive power >
55 kW)
Auto-
tuning
dependent
ƾ
1
4
5
F1-37 Motor auto-tuning method
selection
0: No auto-tuning
1: Static auto-tuning 1
2: Dynamic auto-tuning
3: Static auto-tuning 2
0
ƾ
1
4
3
Group F3: V/F Control Parameters
F3-00 V/F curve setting 0 to 11 0
ƾ
1
4
6
F3-01 Torque boost ¿[HGWRUTXHERRVW
0.1% to 30%
Model
dependent
ƿ
1
4
6
F3-02 Cut-off frequency of torque
boost
0.00 Hz to max. frequency 50.00 Hz
ƾ
1
4
6
F3-03 Multi-point V/F frequency 1 0.00 Hz to F3-05 0.00 Hz
ƾ
1
4
6
F3-04 Multi-point V/F voltage 1 0.0% to 100.0% 0.0%
ƾ
1
4
6
F3-05 Multi-point V/F frequency 2 F3-03 to F3-07 0.00 Hz
ƾ
1
4
6
F3-06 Multi-point V/F voltage 2 0.0% to 100.0% 0.0%
ƾ
1
4
6
F3-07 Multi-point V/F frequency 3 F3-05 to rated motor frequency
(F1-04)
0.00 Hz
ƾ
1
4
6
F3-08 Multi-point V/F voltage 3 0.0% to 100.0% 0.0%
ƾ
1
4
6
F3-09 Slip compensation gain
0.0% to 200.0% 0.0%
ƾ
-
F3-10 V/F over-excitation gain 0 to 200 64
ƿ
1
5
1
F3-11 V/F oscillation suppression
gain
0 to 100 40
ƿ
1
5
1
F3-13 Voltage source for V/F
separation
0 to 8 0
ƿ
1
4
8
F3-14 Digital setting of voltage for V/
F separation
0 V to rated motor voltage 0 V
ƿ
1
4
8
F3-15 Voltage rise time of V/F
separation
0.0s to 1000.0s 0.0s
ƿ
1
4
8
