Inovance MD290T45G/55P User Manual

Appendix
- 309 -
12
Para. No. Para. Name Setting Range Default Property Page
F0-19 Acceleration/Deceleration time
unit
0: 1s
1: 0.1s
2: 0.01s
1
ƾ
1
4
2
F0-21 Frequency offset of Auxiliary
frequency setting channel for
main and auxiliary calculation
0.00 Hz to max. frequency (F0-10) 0.00 Hz
ƿ
-
F0-22 Frequency reference resolution 2: 0.01 Hz 2
ƾ
-
F0-23 Retentive of digital setting
frequency upon stop
0: Not retentive
1: Retentive
0
ƿ
1
1
2
F0-24 Motor parameter group
selection
0: Motor parameter group 1
1: Motor parameter group 2
0
ƾ
1
7
0
F0-25 Acceleration/Deceleration time
base frequency
0: Maximum frequency (F0-10)
1: Frequency reference
2: 100 Hz
0
ƾ
1
4
2
F0-26 Base frequency for UP/DOWN
PRGL¿FDWLRQGXULQJUXQQLQJ
0: Running frequency
1: Frequency Reference
0
ƾ
-
F0-27 Command source + frequency
source
000 to 999
Terminal control + frequency source
The same as that of units position
Operating panel + frequency source
0: Not binding
1: Digital setting
2: AI1
3: AI2
4: AI3
5: Pulse reference (DI5)
6: Multi-reference
7: Simple PLC
8: PID reference
9: Serial comms.
Serial comms. + frequency source
The same as that of units position
000
ƿ
1
3
4
F0-28 Serial port comms. protocol 0: Modbus protocol
1: PROFIBUS-DP protocol or
CANopen protocol
0
ƾ
1
0
9
Group F1: Motor 1 Parameters
F1-00 Motor type selection 0: Common asynchronous motor
1: Variable frequency
asynchronous motor
0
ƾ
1
4
5
F1-01 Rated motor power 0.1 to 1000.0 kW Model
dependent
ƾ
1
4
5
F1-02 Rated motor voltage 1 to 2000 V Model
dependent
ƾ
1
4
5
F1-03 Rated motor current WR$$&GULYHSRZHU
55 kW)
0.1 to 6553.5 A (AC drive power >
55 kW)
Model
dependent
ƾ
1
4
5
F1-04 Rated motor frequency 0.01 Hz to max. frequency Model
dependent
ƾ
1
4
5
F1-05 Rated motor speed 1 to 65535 rpm Model
dependent
ƾ
1
4
5
