Inovance MD290T45G/55P User Manual

3. Electrical Installation
- 54 -
3
Figure 3-5 Terminal dimensions of MD290T132G/160P and MD290T160G/200P
(-)
TRS
(+)
U
WV
POWER
MOTOR
22
315
45
42.5
227
45
M12 flat washer +
spring washer + nut
M10 combination screw
Table 3-6 Recommended cable dimensions and tightening torque of MD290T132G/160P and
MD290T160G/200P
AC Drive Model Rated
Input
Current (A)
Power Input/
Output Cable
Crimp
Terminal
Model
Ground
Cable
Crimp
Terminal
Model
Tightening
Torque (N·m)
Screw
Spec.
MD290T132G 240 3 x 150 mm
2
300 kcmil
150-12 95 mm
2
2 AWG
38-12 35.0 M12
MD290T160P 295 3 x 185 mm
2
300 kcmil
250-12 95 mm
2
2 AWG
38-12 35.0 M12
MD290T160G 287 3 x 185 mm
2
350 kcmil
250-12 95 mm
2
2 AWG
38-12 35.0 M12
MD290T200P 359 3 x 240 mm
2
400 kcmil
325-12 120 mm
2
1/0 AWG
38-12 35.0 M12
