3. Electrical Installation
- 76 -
3
Ƶ
Wiring of Relay
To smooth peak voltage that results from cutting off power to inductive load (relay,
contactor and motor), use a voltage dependent resistor (VDR) at the relay contact and
add absorbing circuit to the inductive load, such as VDR, RC absorbing circuit or diode.
Figure 3-27 Wiring of relay
220 VAC
24 VDC
T/C
T/A
T/B
T/C
T/A
T/B
Ƶ
:LUH6L]HDQG7RUTXH6SHFL¿FDWLRQ
Please use a ferrule-type terminal with insulated sleeves. Prepare wire ends with
insulated sleeves before connecting to the drive. See Figure
3
-
2
8
F
e
r
r
u
l
e
d
i
m
e
n
s
i
o
n
s
below.
Figure 3-28 Ferrule dimensions
6 mm
7DEOH:LUHVL]HDQGWRUTXHVSHFL¿FDWLRQ
Terminal Block Single Wire (AWG/mm
2
) Twisted Wire (AWG/mm
2
) Tightening Torque
(N·m)
Control circuit AWG 24 to 18 (0.2 to 0.75 mm
2
) 0.8 to 1.0
