Inovance MD310 T2.2B - Group U0: Monitoring

5 Parameter Table
- 50 -
5�2 Monitoring Parameters
■
Group U0: Monitoring
Para� No� Para� Name Setting Range Unit Default Commission
U0-00 Running frequency N�A� Hz N�A�
U0-01 Set frequency N�A� Hz N�A�
U0-02 Bus voltage N�A� V N�A�
U0-03 Output voltage N�A� V N�A�
U0-04 Output current N�A� A N�A�
U0-05 Output power N�A� kW N�A�
U0-06 Output torque N�A� % N�A�
U0-07 DI state N�A� N�A� N�A�
U0-08 DO state N�A� N�A� N�A�
U0-09 AI1 voltage N�A� V N�A�
U0-10 AI2 voltage N�A� V N�A�
U0-11 AI3 voltage N�A� V N�A�
U0-12 Count value N�A� N�A� N�A�
U0-13 Length value N�A� N�A� N�A�
U0-14 Load speed N�A� N�A� N�A�
U0-15 PID setting N�A� N�A� N�A�
U0-16 PID feedback N�A� N�A� N�A�
U0-17 PLC stage N�A� N�A� N�A�
U0-18 Input pulse frequency N�A� kHz N�A�
U0-19 Feedback speed N�A� Hz N�A�
U0-20 Remaining running time N�A� Min N�A�
U0-21 AI1 voltage before correction N�A� V N�A�
U0-22 AI2 voltage before correction N�A� V N�A�
U0-23 AI3 voltage before correction N�A� V N�A�
U0-24 Linear speed N�A� m/Min N�A�
U0-25 Accumulative power-on time N�A� Min N�A�
U0-26 Accumulative running time N�A� Min N�A�
U0-27 Pulse input frequency N�A� Hz N�A�
U0-28 Communication setting value N�A� % N�A�
U0-29 Reserved N�A� N�A� N�A�
U0-30 Main frequency X N�A� Hz N�A�
U0-31 Auxiliary frequency Y N�A� Hz N�A�
U0-32 Viewing any register address value N�A� N�A� N�A�
U0-34 Motor temperature N�A� °C N�A�
U0-35 Target torque N�A� % N�A�
U0-37 Power factor angle N�A� ° N�A�
U0-39 Target voltage for V/F separation N�A� V N�A�
U0-40 Output voltage for V/F separation N�A� V N�A�
U0-41 DI state visual display N�A� N�A� N�A�
U0-42 DO state visual display N�A� N�A� N�A�
U0-43 DI function state visual display 1 N�A� N�A� N�A�
U0-44 DI function state visual display 2 N�A� N�A� N�A�
U0-61 AC drive state N�A� N�A� N�A�
