11
NS-AC14PWH5-C
www.insigniaproducts.com
Control panel
#Item Description
1 Timer button Press to set your air conditioner to turn on or off automatically.
2 Swing function
Press and hold the Timer button and Mode button at the same time
for one second to turn on the automatic louver swing.
3 Mode button
Press to cycle your air conditioner through the available modes.
Options include COOL, DRY, and FAN.
4
LED display Temperature/Time
display
Shows the temperature and time left on the timer. The default
temperature is Celsius.
5 Sleep function
Press and hold the Timer button and down
button at same time
for one second to enter into sleep mode. The sleep function is only
available in cooling mode. When your air conditioner enters sleep
mode, the display shows "SL" for 5 seconds, then reverts to the
setting temperature.
6
(TEMP/TIMER) buttons
COOLING mode: Press to raise or lower the temperature setting.
Press at the same time to change from Celsius to Fahrenheit.
TIMER mode: Press to increase or decrease the time.
7 Fan Speed button Press to set the fan speed in cooling mode and fan mode.
8 Power button Press to turn your air conditioner on or off.
