Using your air conditioner
You can control your air conditioner by using the control panel on the top of the unit, or by using the remote control. If
using the remote control, always point it at your air conditioner.
Button Description
Power
Press to turn your air conditioner on or off:
• When you turn your air conditioner on, a tone sounds.
• When you turn your air conditioner off, a tone sounds. Control settings, such as Mode, Set
Temperature, and so on, are retained in memory when the power is off (unless the unit
has been unplugged). When your air conditioner is in standby mode, the display shows
ambient temperature.
Mode
Press to cycle through the operating modes (COOL, DRY, or FAN):
• COOL: The compressor runs and cools the room. Use the
or and Fan Speed buttons
or the High and Low buttons on the remote control to set the desired temperature and
fan speed.
• FAN: The fan circulates the air, but the compressor does not run to cool it. Use the Fan
Speed button to set the desired fan speed. The temperature can’t be changed in Fan
mode.
• DRY: The dehumidifier runs to remove humidity from the air. When entering dry mode, if
the room temperature is ≥17° C (or 62° F), the compressor turns on. Afterwards, the unit
runs as follows:
• When the room temperature is ≤15° C (or 59° F), the compressor turn off.
• When the room temperature is ≥17° C (or 62° F), the compressor restarts (when the
compressor restarts, it will have 3 minute delay protection function).
Fan speed and temperature are not adjustable. The fan speed is preset (at low speed) and
cannot be adjusted. We recommend that you use a drain hose in dry mode (see
Automatically drain water with a hose for dry mode on page 22 for more information).
Note: The LED next to the Mode button displays the active mode.
Fan speed
On the control panel, press this button to cycle through the available fan speeds. The LED next
to the Fan Speed button displays the fan speed. The speed can be selected in either the COOL
or FAN modes.
On the remote control, press this button to turn on the fan only (no cooling).
Down
and Up
• COOL mode: Press to adjust the temperature setting up to 30° C (86° F) or down to 16° C
(60° F), in one degree increments. The temperature can be switched between Fahrenheit
and Celsius by pressing
and at the same time, or by pressing the °F/°C switching
button on the remote control. The default temperature is °C.
Note: In FAN and DRY modes, the temperature displayed is the room temperature (not
the set temperature). In COOL mode, the temperature displayed is the set temperature.
• TIMER mode: Press
to adjust the delay time from one to 24 hours, in one hour
increments.
Timer
Press to set your air conditioner to turn off or turn on after a delay of up to 24 hours.
• Automatic off: Press
while your air conditioner is running to set the delay time
from one to 24 hours, in one hour increments. The air conditioner automatically turns off
when the set delay time is reached.
• Automatic on: Press
while your air conditioner is in standby status to set the delay
time from one to 24 hours, in one hour increments. The air conditioner automatically
turns on when the set delay time is reached.
Press the Timer button to see the delay time you have set on the LED display.
To change the set delay time (on or off):
Press the Timer button, then adjust the time with the
buttons when the number begins
to blink.
To cancel the Timer function:
Press the Timer button, then press it again when the number begins to blink.
