9
3.3 Cu. Ft. 12 Volt Compact Refrigerator
www.insigniaproducts.com
Providing correct ventilation
Place your refrigerator at least 1 in. (2.5 cm) from the wall to make sure that the
airflow to the compressor is adequate. Don’t place your refrigerator near any heat
sources, such as a heater or stove, because this may put a strain on the
compressor.
Connecting power
Selecting the correct type wire
Long lengths for DC voltage supply lines combined with small gauge wiring can
lead to excessive voltage drop at the refrigerator connection. This decreases the
cooling performance of the refrigerator and cause the wires to overheat possibly
causing a fire.
1 Disconnect power by removing the refrigerator circuit fuse or turning off the
circuit breaker in the DC voltage distribution panel.
2 Turn the thermostat control knob to the 0 position.
WARNING: ELECTRICAL SHOCK HAZARD
Failure to follow these instructions can result in death, fire, or electrical shock.
WIRE SIZE THE MAX LENGTH
*14 AWG 3.2 ft.
13 AWG 8 ft.
12 AWG 13 ft.
10 AWG 20 ft.
8 AWG 33 ft.
6 AWG 50 ft.
*14 AWG wire is not recommended. We recommend 13 AWG wire or larger.
Note:
Your refrigerator is not equipped with a power source. Purchase a power source from
an authorized dealer.
