Assembling your file cabinet
STEP 1: Preparing the cabinet back and bottom
You n e ed:
1 Insert three wooden dowels (A) into the edges of the upper back brace (6). Be careful not to insert the dowels into
the KD bolt holes.
2 Insert two large KD cams (E) into the outside holes in the upper back brace (6).
A 7.8 × 30 mm wooden
dowels (15)
D KD Bolt (long) (3)
E KD Cam (large) (5)
Phillips screwdriver
6 Upper back brace
4 Bottom panel
8 Bottom front trim
18 Connection bar (4)
V KD 4 x 22
screw (8)
U 5.8 × 20 mm
wooden dowels (8)
5-1 Mid-cabinet horizontal brace
5-2 Mid-cabinet back brace
KD bolt hole. Do NOT insert dowels here.
Make sure that the arrow in
the cam housing is facing the
hole in the edge of the panel
To Next Page
